Kärcher High-pressure washer HDS 7/16 CXA
Couldn't load pickup availability
BESKRIVNING
Powerful HDS 7/16 CXA three-phase hot water cleaner in the compact class with eco!efficiency mode and automatic hose reel with a 15 m Ultra Guard high-pressure hose.
The HDS 7/16 CXA is a powerful three-phase hot water cleaner in the compact class equipped with an automatic hose reel. It has an air-cooled motor with eco!efficiency mode for energy-efficient operation and a robust axial pump with three ceramic pistons that generates high pressure. The automatic hose reel enables easy insertion and removal of the 15-meter long Ultra Guard high-pressure hose with Teflon® coating, even under pressure, which provides high user comfort and short setup times. The ergonomic EASY!Force The Advanced high-pressure gun with patented nozzle technology and EASY!Lock quick-release couplings simplify work. The Soft Damping System (SDS) reduces vibrations for increased user comfort. The hot water technology effectively dissolves grease and lubricants and reduces the need for cleaning agents, which are precisely dosed from a 15.5-liter tank. Pressure and water flow can be adjusted depending on the task. The HDS 7/16 CXA is easy to maintain and designed for daily use in tough conditions. Features such as descaling, a water filter and a safety valve protect the machine technology. A robust chassis provides shock resistance, while large wheels and a steering wheel/caster ensure high maneuverability.
Features and benefits
Automatic hose reel
- Scratch-resistant and smooth Ultra Guard hose with Teflon® coating
High efficiency
- eco!efficiency mode. Economical and environmentally friendly, even during long periods of use.
- Reduces fuel consumption and CO2 emissions by 20%.
Wide range of accessories with EASY!Lock
- Rotating 1050mm stainless steel lance
Operational reliability
- Easily accessible water filter protects the pump from dirt particles in the water
- Safety valves and protection against water or fuel shortage ensure operational safety of the machine
Reliable
- Water softener to protect the heating coil against calcification.
- The SDS system compensates for vibrations and pressure surges in the high-pressure system.
Many storage options for accessories integrated into the machine
- Storage hooks for power cord and high-pressure hose.
- Integrated spray tube holder for easy transport.
Dosing of cleaning agents
- Precise dosing of detergent with rinse function.
- Large tank opening with filler pipe.
Mobility
- New design with large wheels.
- Easy maneuvering around obstacles, such as steps and curbs.
- Push handle for easy transport and maneuverability.
User-friendly controls
- Easy handling with one control.
Specifications
Technical data
| Mains voltage (Ph/V/ Hz ) | 3 / 400 / 50 |
| Flow rate (l/h) | 310 - 660 |
| Working pressure (bar/MPa) | 30 - 160 / 3 - 16 |
| Max pressure (bar) | 220 |
| Temperature (input 12° C) (°C) | Max. 80 |
| Power (kW) | 4.4 |
| Consumption of heating oil or fuel, full load (kg/h) | 3.6 |
| Fuel oil consumption, eco-efficiency (g/h) | 2.9 |
| Power cable (m) | 5 |
| Nozzle size | 025 |
| Fuel tank (l) | 15 |
| Weight (with accessories) (kg) | 114.3 |
| Weight incl. packaging (kg) | 126.3 |
| Dimensions (L × W × H) (mm) | 1260 x 650 x 920 |
The following is included
- Flush handle: EASY!Force Advanced
- Flush pipe: 1050 mm
- Power nozzle
Standard equipment
- High pressure hose length: 15 m
- SDS System
- built-in automatic hose reel
- Automatic start/stop
- Integrated fuel and detergent tank
Areas of use
- Vehicle cleaning
- Equipment and machine cleaning
- Workshop cleaning
- Cleaning of outdoor areas
- Cleaning of service stations
- Facade cleaning
- Swimming pool cleaning
- Cleaning of sports halls
- Cleaning of production processes
- Cleaning of production systems
