Tool carrier MIC 35
BESKRIVNING
Intuitive MIC 35 implement carrier with smart system for quick changes, comfort cabin with panoramic view and an engine that is well below the emission limits for STAGE V.
Thanks to the latest diesel technology, common rail direct injection and a particulate filter, the MIC 35 implement carrier can be used in urban environments. Its efficient 35 horsepower engine is well below the emission limits for STAGE V and impresses with its economic efficiency. The MIC 35 has a smart overall concept that impresses down to the smallest detail. The large comfort cab with panoramic view and clearly arranged controls, tool-free access to all service areas and the various implement integration options are just a few of the proofs of this. Front implements are easily mounted using the standard three-point linkage, rear implements are installed without stress using the quick-coupling system with hydraulic tilt frame. A multi-coupling for quick and drip-free coupling of the hydraulics is also available as an option, as well as a 35 horsepower engine variant that meets the requirements of the STAGE IIIA emission standard.
Features and benefits
Economical and environmentally friendly to use
- Common rail direct injection and particulate filters reduce emissions to below the requirements of the STAGE V emissions standard.
- For use in green areas in urban areas.
- Lower fuel consumption protects the environment and lowers operating costs.
Integrated quick-change system
- Mounting of front implements via standardized three-point linkage.
- The rear implements are changed using a quick-change system with a hydraulic tilt frame.
- Optional multi-couplers are available for quick and drip-free connection of the hydraulics.
Maximum working comfort
- Largest cab in its class (1.45 m³ air volume), 360° panoramic view, ergonomically and clearly designed.
- Windows on both sides, lockable storage compartment, USB charging socket and bottle holder.
Extremely easy to maintain
- The high-quality components enable very long maintenance intervals of 500 or 1,000 hours.
- Tool-free access to all components requiring maintenance, for example via the pivoting motor cover.
- The cooler can be placed in a special maintenance mode for cleaning.
Specifications
Technical data
| Drive | Diesel |
| Drive motor | All-wheel drive function |
| Engine make | Yanmar |
| Engine power (kW) | 26 |
| Cylinder capacity (cm³) | 1642 |
| Cylinder | 3 |
| Exhaust emission standard | STEP V |
| Fuel tank (l) | 41 |
| Driving speed (km/h) | 25 |
| Working speed (km/h) | 25 |
| Wheelbase (in) | 1500 |
| Permissible total weight (kg) | 2500 |
| Weight without accessories (kg) | 1374 |
| Weight incl. packaging (kg) | 1374 |
| Dimensions (L × W × H) (mm) | 3750 x 1075 x 1980 |
Standard equipment
- Particle filter
- Air conditioning system
- Warmer
- Rotating warning light
- Year-round use
