Two powerful bypass turbines ensure high suction power on the IVR 100/24-2 Ef. This mobile unit can cleanly and safely handle large amounts of dry particles and fine dust.
The IVR 100/24-2 Ef is an industrial vacuum cleaner with a reliable M class filtration system and two powerful bypass turbines with an output of 2.4 kW. These enable the suction of fine dust (down to 0.1 mg/m³), chips and dry particles in large volumes. This mobile mains-operated, single-phase unit has advantages such as a durable, washable pocket filter with manual filter cleaning for constantly high suction power. In its robust overall design, it is perfectly suited for industrial environments. The 100 liter container can be emptied very easily using the large emptying flap without having to remove the motor tops or other parts of the machine. Using a forklift, you can easily lift the machine above, for example, a container thanks to the sockets for the forks in the floor frame.
Features and benefits
Particularly robust, particularly flexible
- With practical, removable suction hose port/pipe bend.
- Very robust machine and chassis with high material thickness
Equipped with two very quiet fan motors
- For powerful suction power and optimal cleaning performance
- The turbines can be switched on separately for individual suction power as desired
- Very quiet drive head ensures even cooling air discharge
Convenient, manual filter cleaning
- Easy operation using an ergonomically placed lever when needed.
- Extends the life of the filter and thus reduces maintenance work.
- Identical cleaning results, regardless of how much force is used.
Equipped with large pocket filter
- For safe vacuuming of solids and dust in dust class M
- Also suitable for large amounts of loose dust
- The special geometry of the filter prevents sucked-in particles from getting stuck.
Specifications
Technical data
| Mains voltage (Ph/V/ Hz ) | 1 / 220 - 240 / 50 - 60 |
| Airflow (l/s/m³/h) | 148 / 532 |
| Vacuuming (mbar/kPa) | 230 / 23 |
| Tank capacity (l) | 100 |
| Connection power (kW) | 2.4 |
| Type of suction | Electrical |
| Nominal diameter of connection | ID 50 |
| Nominal diameter of accessories | ID 50 ID 40 |
| Sound pressure level (dB(A)) | 68 |
| Main filter for dust | M |
| Filter area for main filter (m²) | 1.75 |
| Weight without accessories (kg) | 116 |
| Weight incl. packaging (kg) | 116 |
| Dimensions (L × W × H) (mm) | 950x715x1640 |
